Details
REGULATORS, MOUNT UP!
THE ALL-MOUNTAIN WORKHORSE IS HERE TO DELIVER FUN ON EVERY TRAIL
We are proud to introduce the all-new eMTB platform, the Regulator! The Regulator is the all-mountain workhorse designed to provide a fun, nimble and responsive ride. No trail is too tame or too gnarly for the dedicated mixed wheel platform providing 150/160mm travel and geometry that promotes agility and playfulness. The Regulator will be the choice for riders looking for a chassis that excels everywhere with the added assistance of a Bosch drive unit. The Regulator will be available with the Bosch CX drive unit for those looking for higher power and longer range, or the Bosch SX drive unit for those who desire a lighter weight eMTB experience more similar to a regular mountain bike. Both bikes share similar form language, with just small differences between them, read on below to learn more
NEW REGULATOR CX
The Bosch Performance Line CX powered Regulator packs 85nm of torque with 600 watts of peak power from the 600wh battery and optional 250wh range extender. The main battery is enclosed in a slim downtube and provides hours of fun, while still allowing users to add the range extender if even longer rides are desired. This combination provides the best range to weight ratio for those who value lighter ride characteristics, with the option to ride all day with the range extender. Giving you the best of both worlds with one of the most reliable, powerful and intuitive motor systems available in the market
Features:
• Sizes SM-XL
• Carbon frame, mixed wheel only
• Size specific CS Lengths (442mm SM/MD, 448mm LG/XL)
• 160mm fork travel, 150mm rear travel (160mm compatible with 65mm stroke shock)
• Bosch wireless 2 button Mini Remote
• Top tube mounted System Controller LED display
• New head tube cable routing ports
a. Compatible with 0,1 or 2 cables per side
b. Ideal routing for either right/rear or left/rear brake assemblies
• New chainstay protector design
• Includes separate cable routing grommet or closed plug for wireless RD
• Integrated Transition top chain guide included
• Custom charge port cover w/ integrated range extender cable management
• Bosch Performance Line CX drive unit with 85nm of torque
• Powertube 600wh battery
• Non-removable slide-in assembly for clean looks, minimum DT cross section, durability/robustness, lightest weight and least amount of noise.
• Geo-adjust chip at lower shock mount
• Ideal balance of weight, handling, and power with flexible battery capacity
a. 600wh battery
b. 250wh range extender compatible with MD-XL sizes (sold separately
Specifications:
| Model | Regulator CX Deore | Regulator CX XT |
| Color Options | Salish Sea Blue, Glacier White | Salish Sea Blue, Glacier White |
| Frame | Regulator CX Carbon 150mm | Regulator CX Carbon 150mm |
| Wheel Size | Mixed | Mixed |
| Drive Unit | NEW Bosch Performance Line CX (BDU38) | NEW Bosch Performance Line CX (BDU38) |
| Battery | NEW Bosch PowerTube (600wh) | NEW Bosch PowerTube (600wh) |
| Display | Bosch System Controller | Bosch System Controller |
| Assist Switch | Bosch Wireless Mini Remote | Bosch Wireless Mini Remote |
| Rear Shock | RockShox SuperDeluxe Base (205x60mm) | RockShox SuperDeluxe Ultimate (205x60mm) |
| Fork | RockShox Domain Gold RC (160mm) | RockShox ZEB Ultimate (160mm) |
| Headset | FSA No.57E | FSA No.57E |
| Stem | RaceFace Aefect R (40mm) | ANVL Swage (40mm) |
| Handlebar | RaceFace Chester 35 SM (780x20) MD/LG/XL (780x35) | OneUp Carbon SM (800x20) MD/LG/XL (800x35) |
| Grips | ODI Elite Flow Lock-On | ODI Elite Flow Lock-On |
| Saddle | SDG Bel Air V3 | SDG Bel Air V3 LUX |
| Seatpost | SDG Tellis SM(150mm) MD(170mm) LG(200mm) XL(230mm) | OneUp Dropper Post SM(150mm) MD(180mm) LG(210mm) XL(240mm) |
| Brakes | Shimano Deore M6120 4 Piston | TRP DH-R EVO |
| Rotors | Shimano RT66 (203mm) | TRP R1 2.3 (203mm) |
| Shifter | Shimano Deore M6100 iSpec EV | Shimano XT M8100 |
| Derailleur | Shimano Deore M6100 SGS 12sp | Shimano XT M8100 SGS 12sp |
| Cassette | Shimano Deore M6100 (10-51t) | Shimano XT M8100 (10-51t) |
| Chain | Shimano Deore M6100 | Shimano XT M8100 |
| Crank | Samox EC39 (150mm) | SRAM S1000 (150mm) |
| Chainring | E*Thirteen Helix Core Direct Mount (34t) | E*Thirteen Helix Race Direct Mount (34t) |
| Chainguide | Transition Integrated Top Guide | Transition Integrated Top Guide |
| Rims | WTB ST i30 | DT Swiss H 1900 Spline 30 |
| Spokes | Pillar Straight Gauge | DT Swiss Hybrid 1 |
| Hubs | Novatech D791SB/D902SB | DT Swiss Hybrid 370 |
| Front Tire | Maxxis Assegai 3C EXO+ (2.5) | Schwalbe Albert, Trail Evo, Ultra Soft (2.5) |
| Rear Tire | Maxxis Minion DHRII 3C DD (2.4) | Schwalbe Albert, Trail Evo, Soft (2.5)) |
| Included | Bosch Charger, Tubeless Valves & Sealant | Bosch Charger, Tubeless Valves & Sealant |
| Weight | TBD | 49.2 lbs / 22.32 kg (Size MD - Estimated) |
