UPHOLDING A TIME-TESTED, RACE-BRED ETHOS THAT SAYS NOTHING SHOULD HOLD A RIDER BACK FROM THE SHEER JOY OF UNTETHERED SPEED. BUILT OFF ONE OF THE MOST WINNING RACE PLATFORM IN EWS HISTORY, THE SB160 IS PURE RACE MACHINERY. HONED FOR MORE.
BE FASTEST.
FROM LEGACY TO DYNASTY.
THE YETI/FOX FACTORY TEAM WON 51 EWS STAGES, 12 EWS RACES, AND 1 NATIONAL SERIES CHAMPIONSHIPS ABOARD THE SB150. THE SB160 BUILDS MOMENTUM ON THIS LEGACY OF EXCELLENCE. HONED. REFINED. EVEN EFFING FASTER.
FRAME HIGHLIGHTS:
- NEW Switch Infinity assembly on T-Series
- NEW Threaded bottom bracket
- NEW High-clearance downtube
- NEW Dual-density downtube protection
- Universal Derailleur Hanger (UDH)
- Secure, fully enclosed internal cable management
- Compatible with long dropper posts
- 100% standard sealed Enduro Max bearings
- Floating collet axle pivot design
- Compact-wishbone shock extender
- Downhill tested
- Yeti/Fox Factory team approved
- Boost spacing
- Sizes S-XXL
GEOMETRY
Specifications:
FRAME: C/Series carbon fiber frame, Switch Infinity suspension technology, threaded bottom bracket, fully enclosed internal cable routing,
148mm x 12mm BOOST dropouts, sealed Enduro Max pivot bearings, integrated derailleur hanger, and axle.
REAR SHOCK: FOX FLOAT X2
FRAME TRAVEL: 160MM
FORK TRAVEL: 170MM
LEVERAGE RATE: 17%
WHEEL SIZE: 29"
HEAD TUBE ANGLE: 64º
EFFECTIVE SEAT TUBE ANGLE: 77.5º
Build Kit:
| DETAILS |
C/Series Carbon Frame, 170mm Fox Performance 38 and Float X, SRAM GX T-Type and Code R Brakes |
| FRAME |
C/Series carbon fiber frame, Switch Infinity suspension technology, Threaded BB, internally tunneled cable routing, 148mm x 12mm BOOST dropouts, sealed enduro max pivot bearings, Universal derailleur hanger (UDH), and axle. |
| FORK |
FOX PERFORMANCE 38/170MM |
| MATERIAL |
C/SERIES |
| WEIGHT |
34.13 |
| TRAVEL |
160MM (6.3") |
| REAR SHOCK |
FOX PERFORMANCE FLOAT X |
| WHEELSET |
DT SWISS E1900 30MM |
| REAR DER |
SRAM GX EAGLE AXS TRANSMISSION |
| SHIFT |
SRAM AXS POD CONTROLLER |
| CRANK |
SRAM GX EAGLE TRANSMISSION 30T 170MM |
| BB |
SRAM DUB BSA 73 |
| CASSETTE |
SRAM GX EAGLE TRANSMISSION 10-52 |
| CHAIN |
SRAM GX EAGLE TRANSMISSION FLATTOP |
| BRAKES |
SRAM CODE R |
| ROTORS |
SRAM CENTERLINE 200/SRAM CENTERLINE 200 |
| POST |
ONEUP DROPPER POST 31.6MM / SM: 150MM, MD: 180MM, LG-XXL: 210MM |
| FRONT TIRE |
MAXXIS ASSEGAI 2.5 EXO+ |
| REAR TIRE |
MAXXIS MINION DHR II 2.4 EXO+ |
| HEADSET |
CANE CREEK 40 INTEGRATED |
| BAR |
BURGTEC RIDE WIDE ALLOY ENDURO 35X800MM 30MM RISE |
| STEM |
BURGTEC ENDURO MK3 35X50MM |
| GRIPS |
ODI ELITE PRO |
| SEAT |
SILVERADO CUSTOM |
GEOMETRY
